Ideal for Economic Projects: Perfect for parking lots, warehouses, facades, yards, pathways, and public outdoor lighting.
Power Range: 30W–300W for different outdoor flood lighting applications.
High Efficiency: Up to 140 lm/W for bright illumination with lower energy costs.
Beam Angles: 60° / 90° options for flexible area lighting coverage.
Adjustable Power & CCT: Tri-Power + Single CCT or Tri-Power & Tri-CCT available for better stock control and versatile projects.
Cost-Effective Design: One fixture covers multiple wattages and color temperatures, reducing inventory and purchasing costs.
Adjustable Bracket: Rotatable bracket for easy installation and precise beam direction.
Working Temperature：-25℃ to +45℃
Storage Temperature：-25℃ to +45℃
Working Humidity：0%~85%
Storage Humidity：0%~90%
1. Please use the product in accordance to this instruction
2. Please do not replace components or modify lamps without authorization
Attention
1. Don't install the lamp to non-stable place.
2. Installed by qualified electrician.
3. Switch off the switch box and contact certified electrician if the lamp works abnormally.
| Model No. | ISL-FL06-30W | ISL-FL06-50W | ISL-FL06-100W | ISL-FL06-150W | ISL-FL06-200W | ISL-FL06-250W | ISL-FL06-300W |
| Power | 30W | 50W | 100W | 150W | 200W | 250W | 300W |
| Dimmension | 199*172*37mm | 224*180*37mm | 276*228*41mm | 307*244*43mm | 385*305*44mm | 457*366*44mm | 457*366*44mm |
| Light Efficiency (±5%) | 140lm/W | ||||||
| Beam Angle | 60°/90° | ||||||
| Input Voltage | 120-277VAC, 50/60Hz | ||||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | ||||||
| CRI | 70 | ||||||
| LED | Lumileds/ San'an | ||||||
| Driver | iShineLux | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | IK08 | ||||||
| Operation Temperature | ﹣25°C- +45°C | ||||||
| Lifespan | 50,000H | ||||||
| Warranty | 3/ 5Years | ||||||
